The selection of crushers in the cement industry must focus on the two core links: raw material crushing (limestone, clay, iron ore) and clinker crushing. The key selection indicators include crushing efficiency, energy consumption control, and compatibility with the cement production process. Equipment should be matched according to raw material characteristics and production scale. Below is a specific optimized selection plan:

I. Core Requirements for Crushers in the Cement Industry

Before selecting equipment, it is necessary to clarify industry-specific demands to avoid mismatches between crushers and production needs. Focus on the following 4 dimensions:

1. Adaptability to Raw Material Characteristics

Cement raw materials vary significantly: limestone (low hardness, Mohs 3-4, accounting for 80%-90% of total raw material annual consumption, requiring high-capacity processing), clay (high moisture content, easy to agglomerate, requiring anti-clogging design), and iron ore (high hardness, Mohs 5-6, small dosage but requiring wear-resistant equipment). Crushers must stably process single high-yield raw materials or mixed raw materials.

2. Low Energy Consumption and High Efficiency

Crushing is a high-energy-consuming link in cement production, accounting for 15%-20% of the plant's total energy consumption. The unit energy consumption of crushers should be controlled at ≤8 kW·h/t for limestone and ≤12 kW·h/t for clinker to meet the energy-saving standards of the cement industry.

3. Finished Particle Size Matching Subsequent Processes

• Raw material crushing: The finished particle size must be ≤25 mm to ensure sufficient grinding in the raw mill (reducing mill load and improving grinding efficiency);
• Clinker crushing: The finished particle size must be ≤50 mm to avoid damage to the clinker mill lining and ensure uniform feeding to the mill.

4. Continuous and Stable Operation Capacity

Cement production is a continuous process (annual operation time ≥8000 hours). Crushers must meet the requirements of "low failure rate + easy maintenance": the average trouble-free operation time should be ≥3000 hours, and the replacement time of wearing parts should be ≤2 hours/month to prevent production line shutdown due to equipment failure.

II. Differentiated Selection by Crushing Link

Raw material characteristics and output requirements vary significantly across different crushing links (raw material, clinker). Equipment types should be optimally selected based on specific scenarios.

1. Raw Material Crushing Link: Focus on Limestone, with Compatibility for Multiple Raw Materials

(1) Primary Crushing: Jaw Crusher (First Choice)

Applicable Scenarios: Processing large-size limestone raw ore (500-1000 mm) into 100-150 mm, suitable for medium and large cement plants with clinker output ≥2000 tons per day.

Optimized Selection Points:

• Choose models with large feed openings (feed opening ≥900×1200 mm) to match the particle size of limestone raw ore and eliminate the pre-crushing process;
• Select high manganese steel ZGMn13 liners, which improve wear resistance by 40% and extend the replacement cycle to 3-6 months;
• Equip with hydraulic adjustment devices to quickly adjust the discharge opening gap and reduce downtime for adjustments.

(2) Secondary/Fine Crushing: Impact Crusher/Cone Crusher (Select as Needed)

(3) Special Raw Material Processing: Targeted Configuration

• High-moisture raw materials such as clay: Add vibrating screen pre-screening before crushing to remove agglomerated materials; select toothed roller crushers with anti-slip teeth on the roller surface to prevent material slipping and clogging.
• Small amounts of hard raw materials such as iron ore: Process separately with small cone crushers to avoid wear on main production line equipment.

2. Clinker Crushing Link: Focus on Wear Resistance and Anti-Clogging

Clinker has the characteristics of "high hardness (Mohs 5-6), high temperature (kiln outlet temperature 1200-1300℃, still 100-200℃ after cooling), and easy moisture absorption and agglomeration". Hammer crushers or roller crushers are preferred:

- Hammer Crusher (First Choice for Small and Medium Plants)

• Advantages: Simple structure, large crushing ratio (1:10-1:15), can directly crush clinker to ≤50 mm without secondary crushing;
• Optimization: Use high chromium alloy hammers (Cr26) with high temperature resistance and wear resistance, with a service life of 2-3 months; add liners to the inner wall of the machine body to reduce wear from high-temperature clinker.

- Roller Crusher (First Choice for Large Plants)

• Advantages: No dust splashing during extrusion crushing, uniform finished particle size (deviation ≤3 mm), suitable for large production lines with high environmental protection requirements;
• Optimization: Select double-roller independent drive models, which can adjust roller speed according to clinker hardness to avoid material jamming; the roller surface adopts welded wear-resistant layers, which can be repaired on-site after wear to reduce maintenance costs.

III. Overall Configuration Plans for Cement Plants of Different Scales

1. Small Cement Plants (Clinker Output ≤1000 Tons per Day)

• Configuration: Jaw Crusher (primary crushing) + Impact Crusher (secondary/fine crushing) + Hammer Crusher (clinker crushing)
• Core Advantages: Low investment (total equipment cost approximately 2-3 million RMB), simple process, suitable for small output demands;
• Note: Regularly clean the crushing chamber of the impact crusher to prevent clogging from clay agglomeration.

2. Medium Cement Plants (Clinker Output 1000-5000 Tons per Day)

• Configuration: Jaw Crusher (primary crushing) + Single-Cylinder Hydraulic Cone Crusher (secondary/fine crushing) + Roller Crusher (clinker crushing)
• Core Advantages: Low energy consumption (unit energy consumption 15%-20% lower than small production lines), stable finished particle size, meeting the high-efficiency feeding requirements of raw mills and clinker mills;
• Note: The cone crusher must be equipped with an automatic lubrication system to ensure the bearing temperature ≤70℃ and avoid high-temperature damage.

3. Large Cement Plants (Clinker Output ≥5000 Tons per Day)

• Configuration: Mobile Jaw Crusher (primary crushing, suitable for mine raw material transfer) + Multi-Cylinder Cone Crusher (secondary/fine crushing) + Toothed Roller Crusher (clinker crushing) + Intelligent Control System
• Core Advantages: Full-process automatic control, real-time monitoring of crushing chamber pressure and motor current, fault early warning accuracy ≥90%; multi-cylinder cone crusher with processing capacity 500-1000 t/h, matching large output demands;
• Note: Must be equipped with a pulse dust collector (air handling capacity ≥10000 m³/h) to meet the environmental protection standard of dust emission concentration ≤10 mg/m³.

IV. Selection Pitfalls to Avoid and Post-Optimization Recommendations

• Avoid "overcapacity selection": For example, small plants using large cone crushers. Although the failure rate is low, the equipment investment increases by more than 30%, and energy waste is serious (no-load energy consumption accounts for 40% of rated energy consumption).
• Prioritize "multi-functional models": For example, select jaw crushers with adjustable discharge openings for raw material crushing, which can handle multiple raw materials such as limestone and clay, reducing the number of equipment.
• Post-maintenance optimization: Establish a wearing parts ledger and adjust the replacement cycle according to raw material hardness (e.g., for limestone crushing, replace jaw crusher liners every 3 months and clinker hammer crusher hammers every 2 months); clean the hydraulic system and lubrication system monthly to extend equipment life by more than 30%.
