TLD Mobile cone crushing plant(tyre）

Feed Particle Size: ≤150mm
Processing Capacity: 100-200t/h
Treat materials: Hard rock (granite, basalt, cobblestone), metal ore, construction waste, mine tailings, cement clinker, refractory materials.
Application Area: Mining aggregate production, highway & railway construction, tunnel engineering, metallurgy, chemical industry, hydropower projects, construction waste recycling.

Get A Quote

Product Details:

Shanghai Dongmeng tyre mobile cone crushing plant is an integrated medium & fine crushing unit with cone crusher, feeder and conveyor on tyre chassis. It transfers easily without fixed foundation. Various cone cavities are optional to crush hard materials on site for mobile mining, infrastructure and solid waste recycling projects.

Product Parameters:

Cone Crusher Mobile Crushing Station (tyre）
Model	TLDII2-4015-3	TLDII2-4518-3	TLDII2-5118-3	TLDII2-5421-3
Crusher Model	TZC40TZH1536T	TZC46TZH1848T	TZC51TZH1848T	TZC54TZH2160T
Trailer main belt	B650	B800	B800	B1000
Trailer return material belt	B650	B800	B800	B1000
Trailer finished material belt	2×B400	2×B500	2×B500	2×B650
Transportation length (mm)	16420	17740	17940	18500
Transportation width (mm)	2920	3150	3450	3960
Transportation height (mm)	4330	4780	4950	4950
Working Length (mm)	16510	17830	18030	18590
Working width (mm)	3950	4180	4480	4990
Working height (mm)	4970	5420	5590	6390
Power (kw)	159.64	204.94	234.94	302.94
Trailer Axle	3axle	3axle	3axle	4axle
Weight (T)	45	56	63	78
