The Detailed Process of Sand Making Production Line

A sand making production line is a complete set of crushing and screening system for processing rock, river pebbles, granite, basalt and other stones into qualified machine-made sand, which is widely used in infrastructure construction, concrete mixing station, road engineering and other fields. Many customers want to know the complete workflow before building a production line, and a reliable sand making machine factory can provide customized layout and technical support according to your raw material conditions and output requirements.

1. Raw Material Feeding

Large raw stones are transported to the vibrating feeder by dump trucks. The vibrating feeder evenly feeds the materials into the primary crushing equipment, while removing fine soil and impurities mixed in the raw materials in advance to improve the follow-up crushing efficiency.

2. Primary Crushing (Coarse Crushing)

Jaw crusher is usually used as the primary crushing host. It crushes large lump ore into medium-sized stones that can enter the secondary crushing equipment. For extra hard stone, customers can choose heavy-duty jaw crusher with strong wear resistance.

3. Secondary Crushing (Medium Crushing)

The materials after coarse crushing are conveyed by belt conveyor to cone crusher or impact crusher for medium crushing. Cone crusher is suitable for high hardness rock, while impact crusher is good for stone with medium hardness and requires better grain shape.

4. Sand Making and Shaping

This is the core section of the sand making production line. The medium crushed materials enter the vertical shaft impact sand making machine. Through the principle of stone striking stone and stone striking iron, the materials are crushed and shaped at the same time, so that the finished sand has uniform grain size, good cubic shape and low needle-shaped content.

5. Screening and Grading

The materials discharged from the sand making machine are sent to the vibrating screen. The vibrating screen separates materials of different particle sizes. The finished sand that meets the standard is sent to the finished product pile, while the oversize materials are returned to the sand making machine for re-crushing to form a closed-circuit circulation.

6. Sand Washing (Optional)

If the finished sand has high mud content and the standard is strict, the sand washing machine can be equipped. It removes mud, dust and impurities in machine-made sand to improve the cleanliness of finished sand. Dewatering screen can be matched to reduce the water content of wet sand.

7. Finished Product Storage

Qualified machine-made sand and aggregate are transported to different finished material areas by belt conveyor for stacking and loading. The whole sand making production line can be equipped with centralized electric control cabinet to realize automatic operation, reduce manual cost and monitor the running status of each equipment in real time.

As a professional sand making machine factory, Shanghai Dongmeng Heavy Industry can design fixed and mobile sand making schemes according to your site conditions, hourly output, raw material hardness and finished sand requirements. Our equipment has stable performance, long service life and convenient maintenance, helping you build an efficient and profitable sand production project.
